4H-H-GEARED
MOTOR
|
|
|
▶
Possible to product for needs of ratio beside bellow
chart
아래 표 이외에 감속비 요구 사항 제작
가능
|
|
|
|
MOTOR SPECIFICATION
|
| DESCRIPTION |
CURRENT |
SPEED |
TORQUE |
OUTPUT |
EFF |
| A |
RPM |
g-cm |
W |
% |
| NO
LOAD |
12V |
0.28 |
4800 |
|
|
|
| 24V |
0.14 |
5200 |
|
|
|
| AT
MAX.EFF |
12V |
1.19 |
3880 |
140 |
5.58 |
39.07 |
| 24V |
0.41 |
4260 |
145 |
6.34 |
64.72 |
| AT
STALL |
12V |
5.07 |
|
735 |
|
|
| 24V |
1.90 |
|
800 |
|
|
|
|
|
|
D.C 12V
|
|
|
|
D.C 24V
|
|
GEARED
MOTOR SPECIFICATION
|
| RATIO |
V |
1/32 |
1/43 |
1/50 |
1/82 |
1/100 |
1/120 |
1/165 |
1/200 |
1/250 |
1/300 |
1/375 |
1/420
|
1/466
|
1/520
|
| NO
LOAD(RPM) |
12 |
150 |
111 |
96 |
58 |
48 |
40 |
29 |
24 |
19 |
16 |
12 |
11
|
10
|
9.2
|
| 24 |
162 |
120 |
104 |
63 |
52 |
43 |
31 |
20 |
20 |
17 |
13 |
12
|
11
|
10
|
| ON
LOAD(RPM) |
12 |
121 |
90 |
77 |
47 |
38 |
32 |
23 |
19 |
15 |
13 |
10 |
9.2
|
8.3
|
7.4
|
| 24 |
133 |
99 |
85 |
52 |
42 |
35 |
25 |
21 |
17 |
14 |
11 |
10
|
9.1
|
8.2
|
| TORQUE(Kg-cm) |
12 |
3.2 |
4.3 |
5.1 |
8.3 |
10.2
|
11.0 |
12.0 |
12.0 |
12.0 |
12.0 |
12.0 |
12.0
|
12.0
|
12.0
|
| 24 |
3.3 |
4.5 |
5.2 |
8.6 |
10..5
|
11.4 |
12.0 |
12.0 |
12.0 |
12.0 |
12.0 |
12.0
|
12.0
|
12.0
|
|
